Main harness for the 1000 S (Series 2)

Part number: 29747171

Main harness for the 1000 S (Series 2)

Series 2 machines have the later dash.

Late dash used on the 1000 S (Series 2).
Late dash used on the 1000 S (Series 2).
Late dash used on the 1000 S (Series 2).

Direct link to image

The 1000 S came equipped with variations in the charging system:

  • Saprisa charging system. Voltage regulator was mounted behind the right side cover.
  • Ducati charging system. Voltage regulator was mounted in front of the engine, above the alternator.

The 1000 S came equipped with variations in the ignition system:

  • Standard distributor with coils located behind the left side cover.
  • Digiplex electronic igntion with coils under the fuel tank.

Please let me know which variation you may have.

WANTED: I very much want to reproduce this harness for the 1000 S. Should you have this 1000 S harness suitable for duplication, I would like to speak with you. For more information, e-mail: greg@thisoldtractor.com
